FX3U-48MR-DS Mitsubishi FX3U Series PLC

Brand Name : MITSUBISHI

Model Number : FX3U-48MR-DS

Certification : CE

Place of Origin : Japan

MOQ : 1piece

Price : USD210~245/PCS

Payment Terms : T/T

Supply Ability : 1000PCS/per

Delivery Time : in stock

Packaging Details : Height (mm): 90 Width (mm): 182 Depth (mm): 86 Weight (kg): 0.85

PLC Series : FX3U

Number of Digital Inputs : 24

Number of Digital Outputs : 24

Supply Voltage : 24 VDC

Input Voltage : 24 VDC Sink/Source

Output Type : Relay

Contact Now

FX3U-48MR-DS Mitsubishi FX3U Series PLC

Product Specifications

Part Number: FX3U-48MR-DS
PLC Series: FX3U
Manufacturer: Mitsubishi
Our part number: FX3U48MRDS
Number of Digital Inputs: 24
Input Voltage: 24 VDC Sink/Source
Number of Digital Outputs: 24
Output Type: Relay
Supply Voltage: 24 VDC
Height (mm): 90
Width (mm): 182
Depth (mm): 86
Weight (kg): 0.85

Information about this range

Expandable compact PLC
Available as AC or DC powered
Expandable for up to 384 inputs/outputs
Available with relay or transistor outputs
High speed inputs for fast counting tasks
Three integrated pulse outputs
LEDs for indicating input & output status
Integrated serial interface
A 2nd RS485/422/232 communications interface can be added
Can be mounted on DIN rail or a flat surface
Password access protection
64,000 step program EEPROM memory
Slot for memory cassettes
Integrated real time clock
Integrated positioning control
Exchangable interface & I/O adapter boards
I/O,ADP & special function modules available
User friendly programming systems

FX3U CPU base units

CPU base units with very fast processing time
Versions with up to 256 inputs and outputs
Expanded input/output area for networks and complex applications
Fully compatible with the PROFIBUS/DP network and Ethernet
Can be upgraded by combining with expansion modules
Displays the input and output states via LEDs
Integrated real-time clock

Version:	Capacity:	Dimensions (WxHxD):	Weight:
16 I/Os	25 W/30 VA	130x90x86 mm	0.6 kg
32 I/Os	30 W/35 VA	150x90x86 mm	0.65 kg
48 I/Os	35 W/40 VA	182x90x86 mm	0.85 kg
64 I/Os	40 W/45 VA	220x90x86 mm	1.0 kg
80 I/Os	45 W/50 VA	285x90x86 mm	1.2 kg
128 I/Os	65 VA	350x90x86 mm	1.8 kg

Input/output addresses:	Total max. 384 (incl. released I/Os)
Program memory:	64,000 RAM steps (internal), interchangeable FLROM for simple program exchange
Processing time:	0.065 μs/log. Instruction
Number of instructions:	27 basic orders, 2 sequential control instructions, 209 application instructions
Programming language:	Contact plan, instruction list, SFC
Program processing:	Cyclical execution, process map handling
Program protection:	Password with 3 protection levels
Electrical connection:	Screw terminals
Mounting:	DIN rail
Protection class:	IP10
Ambient temperature:	0°C to +55°C

Approvals

CE, UL/cUL

Mitsubishi FX3U

FX3U CPU's are compatible with existing FX2N expansion modules as well as the new FX3U ADP expansion modules and may be used as a replacement for FX2N PLC's.

Specifications

Not what you’re looking for? Select the attributes you require, then click the button below

	Manufacturer Series	FX3U Series
	Supply Voltage	24 V dc
	Output Type	Relay
	Number of Outputs	24
	Number of Inputs	24
	Input Type	Sink/Source
	Display Included	No
	For Use With	MELSEC FX3U Series
	Expansion Available	Yes
	Output Current	8 A
	Mounting Type	DIN Rail
	Scan Time	0.065 μs
	Operating Mode	Program, Run
	Programming Language Used	Ladder Logic
	Maximum Operating Temperature	+50°C
	Length	182mm
	Total Memory Available	64000 Steps
	Program Capacity	64000 Steps
	Programming Interface	Computer, HMI
	Width	90mm
	Depth	86mm
	Minimum Operating Temperature	0°C
